Dragon Stage
manual type
packing weight: 3450kg
packing volume: 33cbm
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
18.00 m Beam(front) | 4 sets | 3.00 m | 50×3.0 | CS500×600 | 20pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
14.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 6pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Pillar | 4 sets | 3.00 m | 50x3.0 | CS350×350 | 12pcs | |||
2.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
1.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
beam cube | Spigot cube 500x600 | 4pcs | ||||||
Frame Tower | Spigot Sleeve Block M | 4pcs | ||||||
Steel Base M | 4pcs | |||||||
Top Section M | 4pcs | |||||||
Manual hoist,BA05 2Tons | 4pcs | |||||||
Spigot Hinge Section,Height 1m | 4pcs | |||||||
Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
Long outrigger | 16pcs | |||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
Roof Pillar | 4 sets | 1.80 m | 50×3.0 | CS289×289 | 4pcs | |||
14.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs | |||
2.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
1.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
9.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs | |||
2.00 m | 50×3.0 | CS289×289 | 4pcs | |||||
1.20 m | 50×3.0 | CS289×289 | 4pcs | |||||
9.20 m Ladder truss | 12 sets | 3.00 m | 50×3.0 | CL30,289*50 | 24pcs | |||
2.00 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
1.20 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs | |||||
roof conner 5 ways, use for roof beam truss | CS289×289 | 2pcs | ||||||
Connect plate with clamp | 4pcs | |||||||
Single clamp | 24pcs | |||||||
Double clamp | 8pcs | |||||||
roof canopy material:pvc, Blue Colour or customized.and 3 side net curtain | 391.76 | 1pcs | ||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
2.00 m Wings Beam | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 0pcs | |||
2.00 m | 50×3.0 | CS500×600 | 2pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Wings Pillar | 2 sets | 3.00 m | FALSE | CS350×350 | 6pcs | |||
2.00 m | FALSE | CS350×350 | 0pcs | |||||
1.00 m | FALSE | CS350×350 | 0pcs | |||||
Wings Tower | Spigot Sleeve Block M | 2pcs | ||||||
Steel Base M | 2pcs | |||||||
Top Section M | 2pcs | |||||||
Manual hoist,BA05 2Tons + flightcase | 2pcs | |||||||
Spigot Hinge Section,Height 1m | 2pcs | |||||||
Fibre sling,BA04,2 tons 3m | 2pcs | |||||||
Long outrigger | 8pcs | |||||||
Truss Accessory | Conical coupler & Safrty clip & pin | whole set |
pakcing weight: 3500kg
packing volume: 34cbm
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
18.00 m Beam(front) | 4 sets | 3.00 m | 50×3.0 | CS500×600 | 20pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
14.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 6pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Pillar | 4 sets | 3.00 m | 50x3.0 | CS350×350 | 12pcs | |||
2.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
1.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
beam cube | Spigot cube 500x600 | 4pcs | ||||||
Frame Tower | Spigot Sleeve Block M | 4pcs | ||||||
Steel Base M | 4pcs | |||||||
Top Section M | 4pcs | |||||||
Motor hoist, 2Tons | 4pcs | |||||||
Spigot Hinge Section,Height 1m | 4pcs | |||||||
Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
Long outrigger | 16pcs | |||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
Roof Pillar | 4 sets | 1.80 m | 50×3.0 | CS289×289 | 4pcs | |||
14.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs | |||
2.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
1.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
9.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs | |||
2.00 m | 50×3.0 | CS289×289 | 4pcs | |||||
1.20 m | 50×3.0 | CS289×289 | 4pcs | |||||
9.20 m Ladder truss | 12 sets | 3.00 m | 50×3.0 | CL30,289*50 | 24pcs | |||
2.00 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
1.20 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs | |||||
roof conner 5 ways, use for roof beam truss | CS289×289 | 2pcs | ||||||
Connect plate with clamp | 4pcs | |||||||
Single clamp | 24pcs | |||||||
Double clamp | 8pcs | |||||||
roof canopy material:pvc, Blue Colour or customized. | 391.76 | 1pcs | ||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
2.00 m Wings Beam | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 0pcs | |||
2.00 m | 50×3.0 | CS500×600 | 2pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Wings Pillar | 2 sets | 3.00 m | FALSE | CS350×350 | 6pcs | |||
2.00 m | FALSE | CS350×350 | 0pcs | |||||
1.00 m | FALSE | CS350×350 | 0pcs | |||||
Wings Tower | Spigot Sleeve Block M | 2pcs | ||||||
Steel Base M | 2pcs | |||||||
Top Section M | 2pcs | |||||||
motor hoist, 2Tons | 2pcs | |||||||
Spigot Hinge Section,Height 1m | 2pcs | |||||||
Fibre sling,BA04,2 tons 3m + flightcase | 2pcs | |||||||
Long outrigger | 8pcs | |||||||
Truss Accessory | Conical coupler & Safrty clip & pin | whole set |
manual type
packing weight: 3450kg
packing volume: 33cbm
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
18.00 m Beam(front) | 4 sets | 3.00 m | 50×3.0 | CS500×600 | 20pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
14.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 6pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Pillar | 4 sets | 3.00 m | 50x3.0 | CS350×350 | 12pcs | |||
2.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
1.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
beam cube | Spigot cube 500x600 | 4pcs | ||||||
Frame Tower | Spigot Sleeve Block M | 4pcs | ||||||
Steel Base M | 4pcs | |||||||
Top Section M | 4pcs | |||||||
Manual hoist,BA05 2Tons | 4pcs | |||||||
Spigot Hinge Section,Height 1m | 4pcs | |||||||
Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
Long outrigger | 16pcs | |||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
Roof Pillar | 4 sets | 1.80 m | 50×3.0 | CS289×289 | 4pcs | |||
14.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs | |||
2.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
1.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
9.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs | |||
2.00 m | 50×3.0 | CS289×289 | 4pcs | |||||
1.20 m | 50×3.0 | CS289×289 | 4pcs | |||||
9.20 m Ladder truss | 12 sets | 3.00 m | 50×3.0 | CL30,289*50 | 24pcs | |||
2.00 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
1.20 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs | |||||
roof conner 5 ways, use for roof beam truss | CS289×289 | 2pcs | ||||||
Connect plate with clamp | 4pcs | |||||||
Single clamp | 24pcs | |||||||
Double clamp | 8pcs | |||||||
roof canopy material:pvc, Blue Colour or customized.and 3 side net curtain | 391.76 | 1pcs | ||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
2.00 m Wings Beam | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 0pcs | |||
2.00 m | 50×3.0 | CS500×600 | 2pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Wings Pillar | 2 sets | 3.00 m | FALSE | CS350×350 | 6pcs | |||
2.00 m | FALSE | CS350×350 | 0pcs | |||||
1.00 m | FALSE | CS350×350 | 0pcs | |||||
Wings Tower | Spigot Sleeve Block M | 2pcs | ||||||
Steel Base M | 2pcs | |||||||
Top Section M | 2pcs | |||||||
Manual hoist,BA05 2Tons + flightcase | 2pcs | |||||||
Spigot Hinge Section,Height 1m | 2pcs | |||||||
Fibre sling,BA04,2 tons 3m | 2pcs | |||||||
Long outrigger | 8pcs | |||||||
Truss Accessory | Conical coupler & Safrty clip & pin | whole set |
pakcing weight: 3500kg
packing volume: 34cbm
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
18.00 m Beam(front) | 4 sets | 3.00 m | 50×3.0 | CS500×600 | 20pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
14.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 6pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Pillar | 4 sets | 3.00 m | 50x3.0 | CS350×350 | 12pcs | |||
2.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
1.00 m | 50x3.0 | CS350×350 | 0pcs | |||||
beam cube | Spigot cube 500x600 | 4pcs | ||||||
Frame Tower | Spigot Sleeve Block M | 4pcs | ||||||
Steel Base M | 4pcs | |||||||
Top Section M | 4pcs | |||||||
Motor hoist, 2Tons | 4pcs | |||||||
Spigot Hinge Section,Height 1m | 4pcs | |||||||
Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
Long outrigger | 16pcs | |||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
Roof Pillar | 4 sets | 1.80 m | 50×3.0 | CS289×289 | 4pcs | |||
14.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs | |||
2.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
1.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
9.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs | |||
2.00 m | 50×3.0 | CS289×289 | 4pcs | |||||
1.20 m | 50×3.0 | CS289×289 | 4pcs | |||||
9.20 m Ladder truss | 12 sets | 3.00 m | 50×3.0 | CL30,289*50 | 24pcs | |||
2.00 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
1.20 m | 50×3.0 | CL30,289*50 | 12pcs | |||||
Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs | |||||
roof conner 5 ways, use for roof beam truss | CS289×289 | 2pcs | ||||||
Connect plate with clamp | 4pcs | |||||||
Single clamp | 24pcs | |||||||
Double clamp | 8pcs | |||||||
roof canopy material:pvc, Blue Colour or customized. | 391.76 | 1pcs | ||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
2.00 m Wings Beam | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 0pcs | |||
2.00 m | 50×3.0 | CS500×600 | 2pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Wings Pillar | 2 sets | 3.00 m | FALSE | CS350×350 | 6pcs | |||
2.00 m | FALSE | CS350×350 | 0pcs | |||||
1.00 m | FALSE | CS350×350 | 0pcs | |||||
Wings Tower | Spigot Sleeve Block M | 2pcs | ||||||
Steel Base M | 2pcs | |||||||
Top Section M | 2pcs | |||||||
motor hoist, 2Tons | 2pcs | |||||||
Spigot Hinge Section,Height 1m | 2pcs | |||||||
Fibre sling,BA04,2 tons 3m + flightcase | 2pcs | |||||||
Long outrigger | 8pcs | |||||||
Truss Accessory | Conical coupler & Safrty clip & pin | whole set |
