Dragon Stage
packing weight: 2000kg
packing volume: 25cbm
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
12.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 8pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 6pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
7.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS389×389 | 8pcs | |||
2.00 m | 50×3.0 | CS389×389 | 0pcs | |||||
1.00 m | 50×3.0 | CS389×389 | 4pcs | |||||
beam cube | Spigot cube 500x600 | 0pcs | ||||||
Frame Tower | Spigot Sleeve Block M | 4pcs | ||||||
Steel Base M | 4pcs | |||||||
Top Section M | 4pcs | |||||||
Manual hoist,BA05 2Tons | 4pcs | |||||||
Spigot Hinge Section,Height 1m | 4pcs | |||||||
Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
Long outrigger | 16pcs | |||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
Roof Pillar | 2 sets | 1.20 m | 50×3.0 | CS289×289 | 2pcs | |||
9.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs | |||
2.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
1.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
6.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4pcs | |||
2.00 m | 50×3.0 | CS289×289 | 4pcs | |||||
1.20 m | 50×3.0 | CS289×289 | 4pcs | |||||
6.20 m Ladder truss | 8 sets | 3.00 m | 50×3.0 | CL30,289*50 | 8pcs | |||
2.00 m | 50×3.0 | CL30,289*50 | 8pcs | |||||
1.20 m | 50×3.0 | CL30,289*50 | 8pcs | |||||
Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs | |||||
roof conner 5 ways, use for roof beam truss | CS289×289 | 0pcs | ||||||
Connect plate with clamp | 2pcs | |||||||
Single clamp | 16pcs | |||||||
Double clamp | 8pcs | |||||||
roof canopy material:pvc, Blue Colour or customized. | 194.16 | 1pcs |
This system offers several advantages:
Portability: The aluminum construction makes the system lightweight and easy to transport and assemble.
Customizability: The modular design allows for customization to fit specific needs and site conditions.
Durability: Aluminum is a strong and corrosion-resistant material, ensuring the system's longevity.
Versatility: The system can be used for various applications, including temporary shelters, event spaces, and outdoor structures.
Additional Information:
The spigot truss system allows for quick and easy assembly without the need for specialized tools.
The roof truss system can be designed to support different roof coverings, such as fabric, metal sheets, or polycarbonate panels.
The system can be equipped with additional features, such as lighting, sound systems, and climate control.
packing weight: 2000kg
packing volume: 25cbm
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
12.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 8pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
9.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 6pcs | |||
2.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
1.00 m | 50×3.0 | CS500×600 | 0pcs | |||||
7.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS389×389 | 8pcs | |||
2.00 m | 50×3.0 | CS389×389 | 0pcs | |||||
1.00 m | 50×3.0 | CS389×389 | 4pcs | |||||
beam cube | Spigot cube 500x600 | 0pcs | ||||||
Frame Tower | Spigot Sleeve Block M | 4pcs | ||||||
Steel Base M | 4pcs | |||||||
Top Section M | 4pcs | |||||||
Manual hoist,BA05 2Tons | 4pcs | |||||||
Spigot Hinge Section,Height 1m | 4pcs | |||||||
Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
Long outrigger | 16pcs | |||||||
Item | Specification(squre truss) | Qty | ||||||
length | main tube(mm) | size(mm) | ||||||
Roof Pillar | 2 sets | 1.20 m | 50×3.0 | CS289×289 | 2pcs | |||
9.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs | |||
2.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
1.00 m | 50×3.0 | CS289×289 | 0pcs | |||||
6.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4pcs | |||
2.00 m | 50×3.0 | CS289×289 | 4pcs | |||||
1.20 m | 50×3.0 | CS289×289 | 4pcs | |||||
6.20 m Ladder truss | 8 sets | 3.00 m | 50×3.0 | CL30,289*50 | 8pcs | |||
2.00 m | 50×3.0 | CL30,289*50 | 8pcs | |||||
1.20 m | 50×3.0 | CL30,289*50 | 8pcs | |||||
Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs | |||||
roof conner 5 ways, use for roof beam truss | CS289×289 | 0pcs | ||||||
Connect plate with clamp | 2pcs | |||||||
Single clamp | 16pcs | |||||||
Double clamp | 8pcs | |||||||
roof canopy material:pvc, Blue Colour or customized. | 194.16 | 1pcs |
This system offers several advantages:
Portability: The aluminum construction makes the system lightweight and easy to transport and assemble.
Customizability: The modular design allows for customization to fit specific needs and site conditions.
Durability: Aluminum is a strong and corrosion-resistant material, ensuring the system's longevity.
Versatility: The system can be used for various applications, including temporary shelters, event spaces, and outdoor structures.
Additional Information:
The spigot truss system allows for quick and easy assembly without the need for specialized tools.
The roof truss system can be designed to support different roof coverings, such as fabric, metal sheets, or polycarbonate panels.
The system can be equipped with additional features, such as lighting, sound systems, and climate control.
